Amazon Aurora RDS

Integrating Amazon RDS with Osano​

Connecting to Amazon RDS​

In order for Osano to discover data stored in your systems, we must connect to those data providers via an API. We require, at minimum, read-only access to establish a connection to these providers. Each provider you connect may require different information. Please see the linked vendor documentation for instructions on where and how to obtain this data.

Prerequisites​

  • Ensure your postgres/mySQL instance is compatible with the Data API. Check here
  • Enable the Data API for your RDS instance. Enabling Data Api
  • To get the ARN of the RDS cluster, enter this into your AWS CLI:
    • aws rds describe-db-clusters --db-cluster-identifier <NAME> --query DBClusters[0].DBClusterArn
  • Create a secret in AWS Secret Manager:
    • aws secretsmanager create-secret --name osanoSecret --description "Osano's Data API Secret" --secret-string "{\"username\":\"<username>\",\"password\":\"<password>\"}" --query ARN
    • Ensure the secret has the proper permissions to access the RDS cluster.
  • Create an IAM user and attach the following permissions policies.
    • {
         "Version": "2012-10-17",
         "Statement": [
             {
                 "Sid": "SecretsManagerDbCredentialsAccess",
                 "Effect": "Allow",
                 "Action": [
                     "secretsmanager:GetSecretValue"
                 ],
                 "Resource": "arn:aws:secretsmanager:<REGION>:<ACCOUNT_ID>:secret:<SECRET-*>"
             },
             {
                 "Sid": "RDSDataServiceAccess",
                 "Effect": "Allow",
                 "Action": [
                     "rds-data:BatchExecuteStatement",
                     "rds-data:BeginTransaction",
                     "rds-data:CommitTransaction",
                     "rds-data:ExecuteStatement",
                     "rds-data:RollbackTransaction"
                 ],
                 "Resource": [
                     "arn:aws:rds:<REGION>:<ACCOUNT_ID>>:cluster:<OSANO-CLUSTER>",
                     "arn:aws:rds:<REGION>:<ACCOUNT_ID>>:cluster:<OSANO-CLUSTER>"
                     ...
                 ]
             }
         ]
      }
    • Create an Access Key for the user by going into IAM > Users > {Username} > Create Access Key. Note the Access Key ID and Secret Access Key.
    • Have your AWS credentials, cluster ARN, secret ARN, AWS region, and database name ready.

Step by step guide​

  1. Access Data Mapping Settings:

    • Navigate to the Data Mapping page in the Osano application.
    • Select Sources from the left-hand navigation menu.

  2. Select Cloud DB as Source type

  3. From the available SSO sources, select Amazon RDS.

  4. Configure RDS SSO Integration:

    • Follow the on-screen instructions to configure your RDS SSO integration.
    • Enter your Amazon credentials.
    • Enter your Amazon ARNs.
    • Enter your database name.
    • Click Save.

  5. View RDS SSO Integration:

    • Once saved, you will see your RDS SSO integration in the list of configured SSO sources.
    • Your integration will include tables that already exist in your RDS environment.

  6. Click into the Discovered Data to view the tables that synced from RDS.

  7. Create a new data store:

    • To proceed with creating a new data store, click on Review.
    • Follow the prompts to create a new data store.
